FI – IVAN

Product Description

The IVAN stone crusher is the ideal machine for farmers and contractors mainly involved in road maintenance who need to perform professional work even in tough conditions, using tractors equipped with a super reducer or variable transmission. The large working surface and rotor diameter allow the IVAN to be used not only in agriculture but also for road reconstruction, as it crushes the old base (asphalt, concrete, or gravel) and mixes the material with components used to build a new road. Available with single or dual gear transmission.

Standard Equipment

• 3-point universal hitch (Category 3)
• Single-speed unit 1000 rpm
• Reinforced rotor Ø 727 with peaks
• Rotor with Ø 35 peaks in “HIGH-STRENGTH AND WEAR-RESISTANT STEEL”
• Transmission support and idle side support protection rings
• Central PTO shaft with safety bolt (tractor side yoke 1” 3/8 Z6)
• Single side gear transmission in oil bath “by Valentini-4G”
• Idle side support in oil bath
• Bearing supports with special seals “Labyrinth Bearing Protection by Valentini”
• Rear containment sheets and selection grids for crushed product, adjustable with MECHANICAL jack
• Front conveyors adjustable with MECHANICAL jack
• Mechanical depth adjustment of sledges for work depth
• Protective shroud and outer side skid
• Protective counter bonnet in “HIGH-STRENGTH AND WEAR-RESISTANT STEEL”

Safety

• CE Safety protections
• Front protective flaps
• Anti-intrusion protections for transport
• Parking stands

Tractor equipment notes

• Variable transmission
• Hydraulic distributors required: from 2 to 6
• If necessary, equip the tractor with front ballast

MODEL	POWER HP	POWER kW	WORKING WIDTH mm	TOTAL WIDTH mm	NO. OF PEAKS**	WORKING DEPTH ON ROCK BASE* cm	WORKING DEPTH ON SOFT GROUND* cm	ROTOR rpm	WEIGHT* kg
1000	120/190	89/140	1075	1515	80	19	35	245	2250
1300	130/190	96/140	1325	1765	101	19	35	245	2650
1500	140/190	103/140	1575	2015	125	19	35	245	3050

*Approximate **Excluding additional teeth for rotor balancing

TECHNICAL SHEET
